$50.66
Cable Tow Hook for Full Tracked Vehicle
- Military Part Number: 7068219
- Military Description:
HOOK, TOW, CABLE
- National Stock Number (NSN): 2540-00-706-8219, 2540007068219
- Federal Supply Class (FSC): 2540 (Vehicular Furniture and Accessories-10)
- National Item Identification Number (NIIN): 007068219
- Federal Stock Number (FSN): 2540-706-8219, 25407068219
- CAGE numbers: 19207
Cable Towing Hook. Used for M48A5 and M728 Full Tracked Vehicles.
ITEM NAME HOOK,TOW
HOLE DIAMETER 1.516 INCHES MINIMUM AND 1.546
INCHES MAXIMUM
WIDTH 3.750 INCHES NOMINAL
FORK SPAN WIDTH 1.797 INCHES MINIMUM AND 1.890
INCHES MAXIMUM
FORK DEPTH 3.3750 INCHES MINIMUM AND 3.6875
INCHES MAXIMUM
HOOK INSIDE RADIUS 0.625 INCHES MINIMUM AND 0.6875
INCHES MAXIMUM
SMALLEST WIDTH 3.438 INCHES MINIMUM AND 3.562
INCHES MAXIMUM
LENGTH FROM HOLE CENTER TO 4.3750 INCHES MINIMUM AND 4.5625
HOOK HEAD CENTER INCHES MAXIMUM
STYLE DESIGNATOR 7 CABLE
