$10.00
7.50-10 Inner Tube
- Military Part Number: GP5/7.50-10/TR135/OFF CENTER
- Military Description:
INNER TUBE,PNEUMATIC TIRE,VEHICU
- National Stock Number (NSN): 2610-00-405-4365, 2610004054365
- Federal Supply Class (FSC): 2610 (Tires and Tubes, Pneumatic, Except Aircraft)
- National Item Identification Number (NIIN): 004054365
- Federal Stock Number (FSN): 2610-405-4365, 26104054365
AAFU SIZE DESIGNATION 7.50-10
AAFZ BODY MATERIAL RUBBER, NATURAL AND RUBBER,
SYNTHETIC
ABBS INFLATION DEVICE TYPE TR135
ABBT INFLATION DEVICE POSITION OFF CENTER
ABBW CONSTRUCTION REGULAR
ABBX BASE CONSTRUCTION STANDARD
ABBY SPLICE MINIMUM RATED 400 POUNDS PER SQUARE INCH
TENSILE STRENGTH
ASQJ OPERATING TEMP RANGE IN DEG -40.0/51.7
CELSIUS
CQBC MINIMUM TENSILE STRENGTH 1000 POUNDS PER SQUARE INCH
ZZZT NONDEFINITIVE SPEC/STD DATA 5 GROUP
